Core Specifications & Features
Max. working height: 45 meters
Max. working radius: 20 meters
Platform rated load: 200 kg
Boom: 7-section octagonal synchronous telescopic boom
Rotation: 360° continuous rotation
Outriggers: Front & rear V-type, independently adjustable
Control system: CAN bus + wireless remote control, stepless speed regulation
Product Highlights
45m super high lift, wide working range, ideal for overseas high‑altitude applications
Stainless steel working platform with 360° rotation, corrosion‑resistant and durable
7‑section telescopic boom, compact structure, smooth extension, high efficiency
Wireless remote control + dual operating modes with emergency manual operation for enhanced safety
Equipped with anemometer, load sensor and amplitude limit protection; automatic alarm at wind level 5
Soft leg protection: automatically restricts dangerous movements if outriggers are not firmly grounded
Hydraulic and electrical components from world‑famous brands, stable and reliable
Full‑vehicle powder coating and baking process, excellent corrosion resistance
